Description
GC Series 80-260Tons guide plate type hydraulic stamping press
Features
· Highly rigid body, small deformation of the fuselage, and greatly improved tool life.
·Low noise, low vibration, and low cutting noise.
·The number of strokes is adjustable.
·Hydraulic overload protection device, overload automatic emergency stop, protect punch and mold safety.
· Strong left and right eccentric load.
·The fixed-lock six-sided long guide has high precision.
·Human machine interface, easy to operate.
Specifications of GC Series 80-260Tons guide plate type hydraulic stamping press
Item/Specification | Unit | GC160 | GC200 | GC260 |
---|---|---|---|---|
Main pressing capacity | Ton | 160 | 200 | 260 |
Max.stroke | mm | 380 | 410 | 430 |
Daylight opening | mm | 630 | 660 | 680 |
Bolster area L.R×F.B | mm | 1600×680 | 2000×800 | 2300×850 |
Slide area L.R×F.B mm | mm | 1250×500 | 1600×600 | 1900×650 |
Die hole size | mm | - | - | - |
Depth | mm | - | - | - |
System max pressure | Mpa | 18 | 18 | 18 |
System max pressure | mm/sec | 280 | 280 | 280 |
Fast speed up | mm/sec | 280 | 280 | 280 |
Increasing pressure speed | mm/sec | 30 | 30 | 30 |
Main motor power | kw | 15 | 18.5 | 22 |
![Copper anti wear slider of APB series high speed punching press machine](/wp-content/uploads/2018/08/Copper-anti-wear-slider-of-APB-series-high-speed-punching-press-machine-1024x768.jpg)
Copper anti wear slider of GC Series 80-260Tons guide plate type hydraulic stamping press
![Top quality copper anti wear sleeve of APA series universal type progressive stamping precision press](/wp-content/uploads/2018/08/Top-quality-copper-anti-wear-sleeve-of-APA-series-universal-type-progressive-stamping-precision-press-1024x768.jpg)
Top quality copper anti wear sleeve of GC Series 80-260Tons guide plate type hydraulic stamping press
![OMPI clutch used on APA series universal type progressive stamping precision press](/wp-content/uploads/2018/08/OMPI-clutch-used-on-APA-series-universal-type-progressive-stamping-precision-press-768x1024.jpg)
OMPI clutch used on GC Series 80-260Tons guide plate type hydraulic stamping press
![Cnc strip feed for Workshop of APA series universal type progressive stamping precision press](/wp-content/uploads/2018/08/Cnc-strip-feed-for-Workshop-of-APA-series-universal-type-progressive-stamping-precision-press-e1535606120512-1024x768.jpg)
Cnc automatic strip feeder with touch screen of chinese and english language.
